Twin Multi

Application: solution for glass and board with classic grip shape

Frameless system for glass

Number of wingsmin. 1<

Capacity of 40kg per one wing

Ball bearing

Board thickness10 mm

Plate filling

Glass with a thickness of 4, 6 mm

Glass filling

The colors of the handles

natural
white
mat white
mat black
champagne
gold
black
industrial black

Catalog to download

Instructionto download

Configurator for systems

Guide

Scheme of the system

Rails and profiles

name uniwersal upper track lower track GAMA connecting profile TWIN upper horizontal profile TWIN lower horizontal profile TWIN grip TWIN MULTI
number 88840000 88209000 88430000 88440000 88450000 88410000
material
drawing

Basic elements

name GAMA hardware GAMA RAM hardware solid pro guide witch washer symetrical handles - S solid pro guide witch washer asymetrical handles - NS universal stopper SOLID
number 88201000 88301000 88217100 88217200 88807000
material
drawing

Upper racks (interchangeably)

name SOLID tripple upper track SOLID upper track SINGLE upper track
number 88561000 88940000 88740000
material
drawing

Lower racks (interchangeably)

name lower track GAMA II lower track RAMA lower track RAMA SINGLE lower rail L-051 lower track RAMA IV double lower track RAMA IV single clip to tracks GAMA track cover RAMA lower track RAMA IV tripple
number 88930000 88551000 88750000 28630000 88564000 88562000 98203000 88881000 88563000
material
drawing

Guides (interchangeably)

name SOLID PLUS guide - no ball bearing SOLID guide - ball bearing SOLID guide - no ball bearing
number 88217000 88812000 88819000
material
drawing

Stoppers (interchangeably)

name universal stopper stopper RAMA with set screw stopper RAMA lI
number 88802000 88859100 88216000
material
drawing

Track plug

name lower track plug triple RAMA IV lower track plug double RAMA IV lower track plug single RAMA IV upper track plug double upper track plug single
number 88893000 8889200 88891000 88841010 88841030
material
drawing

Optional elements

Optional elements for aluminium systems
